Monitoring System
The station can monitor intercom activity on one or both channelswith individual Listen Level controls. Monitoring intercom activityis possible through a headset, or external earphone or speaker.
Talk Selection
The station contains a mic preamp with limiter and proprietaryspeech-shaping circuits for enhanced intelligibility. An individualelectronic momentary/latching talk button is provided for eachchannel. These buttons light dimly when latched.
Signalling
The station provides individual Call buttons for each channel tosignal all stations on the channel(s). When a remote station operatorsends a Call signal, the CS-702's associated Talk button lightsbrightly, attracting the attention of an operator who have removedtheir headsets or turned off their speakers.
Features:
- Supports up to 40 beltpacks or7speaker stations on 2 channels
- Automatic short-circuit protectionandreset with LED indicators
- Dual-action electronic momentary/latching "Talk" buttons
- Mic- or line-level program withselectable "Program Interrupt"
- "Remote Mic Kill"
- Stage announce with relay
- Individual volume controls foreach channel
- Front-panel headphone connector
- Channel A & B "Link" switch tooperate as a one-channel system
- Front-panel speaker output
- UL approved
- LED buttons for talk, call, announce,link, all talk, or mic on.
